固態電解電容具備環保、低阻抗、高低溫穩定、耐高紋波及高信賴度等優越特性，是目前電解電容產品中最高階的產品，也是很多采購首選的電解電容型號，固態電解電容價格是多少呢？

　　Solid state electrolytic capacitor has the advantages of environmental protection, low impedance, high and low temperature stability, high ripple resistance and high reliability. It is the highest level product in the current electrolytic capacitor products, and is also the preferred electrolytic capacitor model for many buyers. What is the price of solid-state electrolytic capacitor?

　　固態電容全稱固態鋁質電解電容，與普通電容（即液態鋁質電解電容）最大差別在于采用了不同的介電材料，液態鋁電容介電材料為電解液，而固態電容的介電材料則為導電性高分子。固態電解電容價格要根據型號、大小等參數來決定，具體的價格可以咨詢紅寶電子客服。

　　Solid state capacitor is called solid-state aluminum electrolytic capacitor. The biggest difference between solid-state capacitor and common capacitor (i.e. liquid aluminum electrolytic capacitor) is the use of different dielectric materials. The dielectric material of liquid aluminum capacitor is electrolyte, while the dielectric material of solid-state capacitor is conductive polymer. The price of solid-state electrolytic capacitor should be determined according to the model, size and other parameters. The specific price can be consulted with Hongbao electronic customer service.

　　對于怎樣分辨固態電容和電解電容有一個小竅門，那就是在電解電容的頂部如果有“K”或“十”以及“T”等字形的壓痕槽，就說明是電解電容，如果沒有那就是固態電容，但是這個方法只能適用于識別大部分的固態電容，如果是很重要的應用項目，還是要仔細檢查出電容的介質材料來加以區分。固態電容和電解電容并沒有好壞之分，都有各自的優缺點，大家只要合理應用就可以了。

　　There is a trick to distinguish solid-state capacitor from electrolytic capacitor, that is, if there are "K" or "cross" and "t" shaped indentation tank on the top of electrolytic capacitor, it means electrolytic capacitor; if not, it is solid-state capacitor. However, this method can only be used to identify most solid-state capacitors. If it is a very important application project, it should be checked carefully Find out the dielectric material of the capacitor to distinguish. Solid state capacitors and electrolytic capacitors are not good or bad. They have their own advantages and disadvantages. We should use them reasonably.

　　電容元器件在使用不當?shù)那闆r下會出現爆漿的問題，主要是因?yàn)楫?dāng)溫度超過電解液的沸點之后就會出現爆漿，固態電解電容的出現則有效的規避這一缺點，而且固態電解電容有環保、電阻低、壽命長的特點。

　　The main reason is that when the temperature exceeds the boiling point of the electrolyte, the slurry will burst when the temperature exceeds the boiling point of the electrolyte. The appearance of the solid-state electrolytic capacitor can effectively avoid this shortcoming. Moreover, the solid-state electrolytic capacitor has the characteristics of environmental protection, low resistance and long service life.

　　由于固態電容采用導電性高分子產品作為介電材料，該材料不會與氧化鋁產生作用，通電后不致于發生爆炸的現象；同時它為固態產品，自然也就不存在由于受熱膨脹導致爆裂的情況了。

　　As the solid state capacitor uses conductive polymer products as dielectric materials, the material will not react with alumina and will not explode after being electrified; at the same time, it is a solid product, so there will be no explosion due to thermal expansion.

　　由于固態電容特性遠優于液態鋁電容，固態電容耐溫達260度，且導電性、頻率特性及壽命均佳，適用于低電壓、高電流的應用，主要應用于數字產品如薄型DVD、投影機及工業計算機等，近年來也被電腦板卡產品廣泛使用。

　　Because the solid-state capacitance is much better than the liquid aluminum capacitor, the solid-state capacitor has a temperature resistance of 260 degrees, good conductivity, frequency characteristics and service life. It is suitable for low-voltage and high-current applications. It is mainly used in digital products such as thin-film DVD, projector and industrial computer, and is widely used in computer board products in recent years.

　　從電氣性能上講，固態電解電容最大的優點在于沒有使用液態的電解液，這樣在受熱時不容易發生“脹肚”、“爆裂”等情況，使用壽命長、熱穩定性好，適合于高頻的工作環境；后者價格便宜、容量大、耐壓值高。

　　In terms of electrical performance, the biggest advantage of solid-state electrolytic capacitor is that it does not use liquid electrolyte, so it is not easy to "bulge" and "burst" when heated. It has a long service life and good thermal stability, which is suitable for high-frequency working environment; the latter is cheap, large capacity and high withstand voltage value.
